CLPI系列
| POHO | Product Number | Dimensions L*W*T(mm) | Inductance Range(uH) | Rdc Range(mΩ) | Rated Current(A) | Data sheet |
 |
CLPI-201610G | 2.0*1.6*1.0 | 0.47~2.2 | 28~130 | 1.8~6.3 |  download 下载 |
|
CLPI-252010G | 2.5*2.0*1.0 | 0.33~4.7 | 13~240 | 1.4~7.4 | download 下载 |
|
CLPI-252010C | 2.5*2.0*1.0 | 0.47~10 | 32~650 | 0.8~4.8 | download 下载 |
|
CLPI-252012G | 2.5*2.0*1.2 | 0.33~4.7 | 12~190 | 1.5~8.3 | download 下载 |
|
CLPI-252012C | 2.5*2.0*1.2 | 0.47~10 | 26~450 | 1.0~4.9 | download 下载 |
CLPW系列
| POHO | Product Number | Dimensions L*W*T(mm) | Inductance Range(uH) | Rdc Range(mΩ) | Rated Current(A) | Data sheet |
 |
CLPW-201610P | 2.0*1.6*1.0 | 0.24~2.2 | 17~150 | 1.5~5.6 | download 下载 |
|
CLPW-201610S | 2.0*1.6*1.0 | 0.1~2.2 | 10~140 | 2.0~9.0 | download 下载 |
|
CLPW-252010P | 2.5*2.0*1.0 | 0.22~4.7 | 9~262 | 1.22~7.9 | download 下载 |
|
CLPW-252010S | 2.5*2.0*1.0 | 0.33~4.7 | 17~240 | 1.4~7.8 | download 下载 |
|
CLPW-252012P | 2.5*2.0*1.2 | 0.47~4.7 | 21~235 | 1.4~5.3 | download 下载 |
|
CLPW-252012S | 2.5*2.0*1.2 | 0.47~2.2 | 16~89 | 2.2~6.8 | download 下载 |
|
CLPW-322512A | 3.2*2.5*1.2 | 0.47~6.8 | 18~210 | 1.2~7.7 | download 下载 |
CXAL 扁平线系列
| POHO | Product Number | Dimensions L*W*T(mm) | Inductance Range(uH) | Rdc Range(mΩ) | Rated Current(A) | Data sheet |
 |
CXAL-4020A**-D | 4.4*4.4*1.9 | 0.1~2.2 | 2.2~38.7 | 5.6~33 | download 下载 |
|
CXAL-4020LR**-D | 4.4*4.4*1.9 | 0.47~4.7 | 6.0~57.2 | 3.5~13.2 | download 下载 |
|
CXAL-4030A**-D | 4.4*4.4*2.8 | 0.47~2.2 | 6.6~20.8 | 6.2~15 | download 下载 |
|
CXAL-4030LR**-D | 4.4*4.4*2.8 | 0.9~6.8 | 9.1~74.1 | 4.0~11.2 | download 下载 |
|
CXAL-4040A**-D | 4.4*4.4*3.8 | 0.47~3.3 | 5.2~31.5 | 6.0~15 | download 下载 |
|
CXAL-5020A**-D | 6.0*5.7*1.9 | 0.15~1.5 | 4.0~18.7 | 8.8~27 | download 下载 |
|
CXAL-5030A**-D | 6.0*5.7*2.9 | 0.15~4.7 | 2.1~36.3 | 5.9~32.5 | download 下载 |
|
CXAL-5030LR**-D | 6.0*5.7*2.9 | 0.27~5.6 | 2.15~34.1 | 5.9~28 | download 下载 |
|
CXAL-5050LR**-D | 6.0*5.7*4.8 | 5.6~22 | 22~99.7 | 3.4~7.2 | download 下载 |
|
CXAL-6030A**-D | 7.2*6.9*2.8 | 0.18~4.7 | 1.6~29.2 | 6.0~36 | download 下载 |
|
CXAL-6040A**-D | 7.2*6.9*3.8 | 0.47~5.6 | 2.6~28.1 | 6.7~27 | download 下载 |
|
CXAL-6050A**-D | 7.2*6.9*4.8 | 0.82~8.2 | 3.8~31.5 | 6.2~21 | download 下载 |
|
CXAL-6060A**-D | 7.2*6.9*5.8 | 1.0~10 | 4.0~36.3 | 5.8~21 | download 下载 |
|
CXAL-6060LR**-D | 7.2*6.9*5.8 | 1.0~22 | 3.9~60.5 | 5.0~19 | download 下载 |
|
CXAL-7020A**-D | 8.4*8.0*1.9 | 0.15~1.8 | 1.9~19.8 | 8.0~46 | download 下载 |
|
CXAL-7030A**-D | 8.4*8.0*2.9 | 0.33~10 | 2.0~56.1 | 5.0~40 | download 下载 |
|
CXAL-7050A**-D | 8.4*8.0*4.8 | 0.16~5.6 | 0.9~17.2 | 10.0~68 | download 下载 |
|
CXAL-7070A**-D | 8.4*8.0*6.7 | 2.2~10 | 5.73~26.4 | 7.0~17.8 | download 下载 |
|
CXAL-1006A**-D | 11.9*11.0*5.7 | 0.68~10 | 1.25~18.2 | 9.0~50 | download 下载 |
|
CXAL-1010A**-D | 11.9*11.0*9.7 | 2.2~15 | 2.5~19.3 | 12.5~32 | download 下载 |
|
CXAL-1031LR**-D | 11.9*11.0*2.9 | 0.28~1.5 | 1.45~6.6 | 18~58 | download 下载 |
|
CXAL-1508A**-D | 17.5*16.5*7.7 | 0.4~22 | 0.55~23.2 | 12~101 | download 下载 |
|
CXAL-1510A**-D | 17.5*16.5*9.7 | 4.7~33 | 3.4~20.0 | 13~39 | download 下载 |
|
CXAL-1513A**-D | 17.5*16.5*12.7 | 4.7~33 | 3.0~22.2 | 14~40 | download 下载 |
CMDC 碳基粉系列
| POHO | Product Number | Dimensions L*W*T(mm) | Inductance Range(uH) | Rdc Range(mΩ) | Rated Current(A) | Data sheet |
 |
CMDC-3012H | 3.5*3.2*1.0 | 0.15~10 | 9.6~550 | 1.0~14 | download 下载 |
|
CMDC-3015H | 3.5*3.2*1.3 | 0.22~10 | 14~522 | 1.2~10.8 | download 下载 |
|
CMDC-3018H | 3.5*3.2*1.6 | 0.47~15 | 21.5~600 | 1.2~8.5 | download 下载 |
|
CMDC-3020H | 3.5*3.2*1.8 | 0.1~10 | 6.6~422 | 1.4~14 | download 下载 |
|
CMDC-4012HP | 4.45*4.06*1.0 | 0.033~22 | 2.0~1050 | 0.8~40 | download 下载 |
|
CMDC-4015HP | 4.45*4.06*1.3 | 0.047~10 | 2.1~400 | 1.5~48 | download 下载 |
|
CMDC-4018HP | 4.45*4.06*1.6 | 0.22~10 | 6.6~265 | 1.65~21 | download 下载 |
|
CMDC-4020HP | 4.45*4.06*1.8 | 0.047~22 | 1.9~500 | 1.2~35 | download 下载 |
|
CMDC-4030HP | 4.45*4.06*2.8 | 1.0 | 14~17 | 7.0~9.0 | download 下载 |
|
CMDC-5012HP | 5.7*5.2*1.0 | 0.1~15 | 4.3~470 | 1.3~14.5 | download 下载 |
|
CMDC-5015HP | 5.7*5.2*1.3 | 0.1~22 | 2.75~466 | 1.2~35 | download 下载 |
|
CMDC-5018HP | 5.7*5.2*1.6 | 0.1~15 | 2.5~318 | 1.7~40 | download 下载 |
|
CMDC-5020HP | 5.7*5.2*1.8 | 0.1~22 | 3.6~390 | 1.5~45 | download 下载 |
|
CMDC-5030H | 5.7*5.2*2.8 | 0.1~22 | 2.2~250 | 2.2~40 | download 下载 |
|
CMDC-5030HP | 5.7*5.2*2.8 | 0.1~33 | 2.5~44 | 1.6~27 | download 下载 |
|
CMDC-5030T | 4.9*4.7*2.8 | 0.1~4.7 | 2.0~60 | 4.5~34 | download 下载 |
|
CMDC-6012H | 7.0*6.6*1.0 | 0.1~22 | 3.3~600 | 1.2~30 | download 下载 |
|
CMDC-6015H | 7.0*6.6*1.3 | 0.1~33 | 2.5~750 | 1.2~35 | download 下载 |
|
CMDC-6018H | 7.0*6.6*1.6 | 0.1~33 | 2.1~650 | 1.3~45 | download 下载 |
|
CMDC-6020H | 7.0*6.6*1.8 | 0.1~22 | 2.0~280 | 1.5~40 | download 下载 |
|
CMDC-6024H | 7.3*6.6*2.2 | 0.1~22 | 1.4~215 | 1.8~70 | download 下载 |
|
CMDC-6030H | 7.3*6.6*2.8 | 0.1~47 | 1.2~363 | 1.75~60 | download 下载 |
|
CMDC-6040H | 7.3*6.6*3.8 | 0.12~47 | 0.7~350 | 1.8~64 | download 下载 |
|
CMDC-6050H | 7.3*6.6*4.8 | 0.1~82 | 0.65~500 | 1.1~65 | download 下载 |
|
CMDC-8030HP | 8.8*8.3*2.8 | 0.33~33 | 2.2~240 | 2.8~47 | download 下载 |
|
CMDC-8040HP | 8.8*8.3*3.8 | 0.22~22 | 1.6~120 | 3.9~60 | download 下载 |
|
CMDC-1002H | 11.0*10.0*1.8 | 1.0~8.2 | 15~105 | 3.2~26 | download 下载 |
|
CMDC-1003H | 11.0*10.0*2.8 | 0.15~47 | 0.9~260 | 2.0~60 | download 下载 |
|
CMDC-1004H | 11.0*10.0*3.8 | 0.1~100 | 0.35~420 | 1.3~85 | download 下载 |
|
CMDC-1005H | 11.0*10.0*4.8 | 0.22~100 | 0.45~380 | 2.0~70 | download 下载 |
|
CMDC-1203HP | 13.5*12.5*2.8 | 0.36~47 | 2.2~280 | 2.5~50 | download 下载 |
|
CMDC-1235HP | 13.5*12.5*3.3 | 0.1~47 | 0.36~218 | 3.0~84 | download 下载 |
|
CMDC-1205HP | 13.5*12.5*4.8 | 0.22~82 | 0.5~238 | 3.0~110 | download 下载 |
|
CMDC-1206HP | 13.5*12.5*5.7 | 0.22~220 | 0.48~550 | 2.0~120 | download 下载 |
|
CMDC-1265HP | 13.5*12.5*6.2 | 0.15~330 | 0.49~780 | 1.8~118 | download 下载 |
|
CMDC-1707HP | 17.6*16.9*6.7 | 0.22~150 | 0.63~168 | 4.6~135 | download 下载 |
|
CMDC-2313HP | 23.8*22.0*12.6 | 3.3~82 | 1.7~40 | 11.5~70 | download 下载 |
|
CMDC-110704H | 11.0*7.1*3.8 | 0.15~0.22 | 0.35~0.51 | 35~70 | download 下载 |
|
CMDC-110705H | 11.0*7.1*4.8 | 0.15~0.33 | 0.45~1.3 | 32~110 | download 下载 |
|
CMDC-120804H | 13.0*8.0*3.8 | 0.22~0.47~ | 0.45~1.2 | 35~80 | download 下载 |
CMDA 合金粉系列
| POHO | Product Number | Dimensions L*W*T(mm) | Inductance Range(uH) | Rdc Range(mΩ) | Rated Current(A) | Data sheet |
 |
CMDA-4010SP | 4.45*4.1*1.0 | 1.0~10 | 42~340 | 1.4~5.0 | download 下载 |
|
CMDA-4010S | 4.2*4.15*0.83 | 2.2~10 | 80~320 | 1.6~3.0 | download 下载 |
|
CMDA-4015SP | 4.45*4.1*1.3 | 0.47~1.5 | 13~48 | 4.5~8.0 | download 下载 |
|
CMDA-4020SP | 4.45*4.1*1.8 | 0.1~10 | 2.9~215 | 2.1~26 | download 下载 |
|
CMDA-5012SP | 5.7*5.2*1.0 | 0.47~0.68 | 10~17 | 7.0~11 | download 下载 |
|
CMDA-5015SP | 5.7*5.2*1.3 | 1.0~6.8 | 20~160 | 2.5~7.5 | download 下载 |
|
CMDA-5020SP | 5.7*5.2*1.8 | 0.1~22 | 2.3~325 | 1.9~29 | download 下载 |
|
CMDA-5030S | 5.7*5.2*2.8 | 0.1~22 | 2.0~228 | 2.0~33 | download 下载 |
|
CMDA-5030T | 4.9*4.7*2.8 | 0.1~4.7 | 1.8~52 | 4.0~32 | download 下载 |
|
CMDA-6010SP | 6.1*6.1*0.8 | 4.7~10 | 140~310 | 1.7~3.5 | download 下载 |
|
CMDA-6015S | 7.0*6.6*1.3 | 0.1~8.2 | 2.35~169 | 2.7~32 | download 下载 |
|
CMDA-6018S | 7.1*6.6*1.6 | 0.15~2.2 | 1.9~33.5 | 7.0~30 | download 下载 |
|
CMDA-6020S | 7.1*6.6*1.8 | 0.15~10 | 2.0~140 | 3.4~40 | download 下载 |
|
CMDA-6024S | 7.1*6.7*2.2 | 0.1~10 | 1.2~93 | 3.7~70 | download 下载 |
|
CMDA-6030S | 7.1*6.6*2.8 | 0.1~47 | 1.1~300 | 1.8~45 | download 下载 |
|
CMDA-6040S | 7.1*6.6*3.8 | 0.12~6.8 | 0.75~38 | 6.8~50 | download 下载 |
|
CMDA-6050S | 7.3*6.6*4.8 | 0.15~47 | 1.3~320 | 1.8~45 | download 下载 |
|
CMDA-8040SP | 9.5*8.5*3.8 | 0.1~0.33 | 0.42~1.9 | 28~52 | download 下载 |
|
CMDA-1002S | 11.0*10.0*1.8 | 0.24~2.2 | 2.8~15.5 | 10~32 | download 下载 |
|
CMDA-1003S | 11.0*10.0*2.8 | 0.22~8.2 | 0.9~38 | 7.2~50 | download 下载 |
|
CMDA-1004S | 11.0*10.0*3.8 | 0.15~100 | 0.5~310 | 2.0~82 | download 下载 |
|
CMDA-1045S | 11.0*10.0*4.3 | 0.3~110 | 0.67~290 | 2.2~55 | download 下载 |
|
CMDA-1005S | 11.0*10.0*4.8 | 2.2~4.7 | 5.8~13.5 | 12~18 | download 下载 |
|
CMDA-1054S | 11.0*10.0*5.1 | 4.7~68 | 8.3~152 | 3.3~15.7 | download 下载 |
|
CMDA-1205SP | 13.5*12.6*4.7 | 0.22~150 | 0.56~336 | 2.7~65 | download 下载 |
|
CMDA-1206SP | 13.5*12.6*5.7 | 0.36~150 | 0.65~325 | 2.6~70 | download 下载 |
|
CMDA-1265SP | 13.5*12.6*6.2 | 0.1~100 | 0.2~161 | 5.0~120 | download 下载 |
|
CMDA-120803S | 12.7*8.1*2.8 | 0.22~0.47 | 0.6~1.6 | 29~60 | download 下载 |
|
CMDA-120804S | 12.7*8.1*3.8 | 0.22~0.47 | 0.4~1.2 | 35~75 | download 下载 |
|
CMDA-1707SP | 17.8*16.9*6.7 | 0.47~100 | 0.7~105 | 6.0~110 | download 下载 |
|
CMDA-2313SP | 23.5*22.0*12.6 | 1.5~100 | 1.0~40 | 9.0~62 | download 下载 |
